Silicon wafer 4inch P/N Type 1~10Ω Oxide Layer Semiconductor Substrate

$50.00
Specification:P(100) 525um Oxide Layer 100nm
Quantity:1 Piece
Quantity:
♦️High-quality silicon wafer for Research and Experiment.
♦️Provide small quantities, special specifications products, and customized services.
♦️Global shipping, secure payment, large inventory.
♦️Minimum delivery time within 1 week. Shipped by FedEx, DHL,UPS, etc.
Silicon Wafer Specification:
  • Size: 4inch;
  • Method: CZ;
  • Type: P;
  • Dopant: B;
  • Orientation:100;
  • Resistivity: 1~10Ω;
  • Thickness: 525um±25;
  • Oxide film: 280/300/500nm (both sides);
  • TTV＜10um ;
  • Surface: polished;
  • Backside: etched;
  • Packing: silicon wafer case ;
